Description
Singular Motorsports 3” brake ducts for 1990-2005 Miatas
Our 3″ brake ducts are designed to fit all 1990-2005 Miatas with wheel sizes 14″ and up.
Note: There are some limitation to the hose size which you can run to the ducts:
2.5″ hose is compatible with the factory under trays, requiring little to no modifications . We recommend the 2.5″ brake ducts for those who want the most cooling ability with the least amount of modification. 2.5″ hose can clear 15×9″ wheels with the factory undertray intact and without the use of any spacers.
In most cases, 3” hose requires a non-factory or fabricated under tray to clear 9” wheels or larger. With the factory plastic undertray removed, 3″ hose will clear 15×9 and 15×10 with a 5mm spacer.
We recommend users run the largest size brake ducts that they are able to accommodate on their car. Brake pad and rotor life is increased further with the larger diameter units, as well as a larger reduction in operating temperatures.
johnny –
I installed these after a track day even that my brakes overheated. i lost all braking going into turn 3. 3 months later i went back to the same track (CMP) on a hotter day. all the equipment was exactly the same and the car worked flawlessly.
Vehicle details.
1999 NB PFC 01 pads, 11.75″ PFC rotors, TSE kIt.
Pablo M. –
Love these. Very easy to install. Nice clean fabrication. Highly recommend.
Dave M. –
Removing the old disc back plates was easy, following the Singular Motorsports instructions. I used a pair of aviation style snips to cut out a “vee” segment out from its edge as close to the hub as I could, and then twisted the plate back and forth a couple of times and off they came.
Installing the new back plates was easy, as each one fit perfectly.
James G. –
The difference on track is stunning. Far more consistent brakes adds confidence and improves lap time. I highly recommend this kit for the track enthusiast.
